JM150T-19B
JM150T-19B
Practical
demonstration
details
Basic parameters
| 150CC | 150CC | 125CC EEC | |
| L*W*H(mm) | 1900x720x1250 | 1900x720x1250 | 1900x720x1250 |
| Wheel base(mm) | 1350 | 1350 | 1350 |
| Engine model | 149.9ml | 149.6ml | 123.578ml |
| Engine type | single cylinder,4stroke,water-cooled,2valves | single cylinder,4stroke,air-cooled,2valves | single cylinder,4stroke,air-cooled,2valves |
| Bore*stroke(mm) | 57.3*58 | 57.4*57.8 | 53.5*55 |
| Maximum power Kw/(r/min) | 10.5/8500 | 6.8/7000 | 6.8/7500 |
| Max torque N.m/(r/min) | 14.0/5500 | 9.8/6000 | 9.5/6000 |
| Fuel supply | EFI | carburettor | EFI |
| Max speed(km/h) | 95 | 85 | 85 |
| Fuel capacity(L) | 6.6 | 6.6 | 6.6 |
| Brake(front/rear) | disc/disc | disc/disc | disc/disc |
| Tire(front/rear) | 120/70-12,120/70-12 | 120/70-12,120/70-12 | 120/70-12,120/70-12 |
| Net weight(kg) | 120 | 108 | 108 |
